EVGA GEFORCE GTX 980 TI FTW GAMING ACX 2.0PLUS
Product Description
EVGA GeForce GTX 980 Ti FTW GAMING ACX 2.0plus
Introducing the EVGA GeForce GTX 980 Ti FTW. Accelerated by the groundbreaking NVIDIA Maxwell architecture, the EVGA GeForce GTX 980 Ti FTW ups the game with dual 8-Pin Power inputs, 8+2 Phase Power Design, Dual BIOS’s and an included EVGA backplate. Not to mention this card packs 2816 NVIDIA CUDA Cores and 6GB of GDDR5 memory, giving you the horsepower to drive whatever comes next. In fact, the EVGA GeForce GTX 980 Ti FTW provides over 3x the performance and 3x the memory of previous-generation cards*.
This card also features EVGA ACX 2.0+ cooling technology. EVGA ACX 2.0+ brings new features to the award winning EVGA ACX 2.0 cooling technology. A memory MOSFET Cooling Plate (MMCP) reduces MOSFET temperatures up to 13%, and optimized Straight Heat Pipes (SHP) additionally reduce GPU temperature by 5C. ACX 2.0+ coolers also feature optimized swept fan blades, double ball bearings and an extreme low power motor, delivering more air flow with less power, unlocking additional power for the GPU.
*GeForce GTX 680
dBi-dB Noise InverterEVGA’s ACX 2.0+ fan turns off below 60°C, generating 0dB of noise.
QSD BIOS – Quick Switch Dual BIOSMultiple integrated BIOSes allow you to switch to the secondary with the flick of a switch.
MMCP – Memory MOSFET Cooling PlateFull size cooling base plate makes contact with memory and MOSFETs, reducing memory temperature up to 15°C and MOSFET temperature up to 13°C.
OPT – Optimized Power TargetThe power target is precisely tuned for the perfect balance of thermal, power and performance, offering 33% more power over reference.
SHP – Straight Heat PipesTriple 8mm straight heat pipes offer 6% better heat dissipation than bent heat pipes with reduced thermal resistance.
IMPROVED COOLING
REDUCED FAN NOISE
BETTER OVERCLOCKING
WHY DOUBLE BALL BEARINGS
EVGA ACX 2.0+ fans use double ball bearings, which offer 400% longer lifespan than the sleeve bearing fans used by competitors. The oil that is used in Sleeve bearing fans makes them vulnerable and prone to failure after time when the oil dries up. Upgrade to EVGA ACX 2.0+ and your card will go the distance!
BUILT WITH 6GB OF HIGH PERFORMANCE GDDR5 MEMORY
6GB of High Performance memory running at extreme clockspeeds giving you access to highter texture qualities in games, improved 4K gaming performance and optimized for the next generation of gaming.
EVGA ACX 2.0+ MEANS BETTER OVERCLOCKING
Did you know that power consumption of the fans can directly affect your maximum overclock? The maximum “power target” takes into account the fan power consumption, meaning the lower the power consumption from the fan, the more power available for the card. EVGA ACX 2.0+ coolers use more than 4X lower power than competitors allowing for better and more stable overclocks. In some cases, just a few watts of additional power for the card can provide an additional headroom of up to +25MHz higher GPU or +350MHz memory frequency!
BUILT FOR DIRECTX® 12
Introducing EVGA PrecisionX™ 16 version 5.3.5 with full support for Microsoft DirectX® 12 OSD support. This latest version of EVGA PrecisionX™ adds new features, overclocking support, functionality, and full support for the upcoming Microsoft DirectX® 12 API.
Key Features
- Full support for Microsoft DirectX® 12 API
- Redesigned OSD interface with RGB color support
- Available on Steam or as a separate download
EVGA GEFORCE GTX 980Ti COMPARISON CHART
| EVGA GRAPHICS CARD | PART NO. | BASE/BOOST CLOCK | BIOS | COOLER | POWER TYPE | POWER PHASE | MAX POWER DRAW | PERFORMANCE | BACKPLATE |
| EVGA GeForce GTX 980 Ti K|NGP|N ACX 2.0+ | 06G-P4-5998 | 1203/1304/7010 | Triple | ACX 2.0 | 8+8+6-Pin | 14+3 | 300W | Ultra Extreme | Yes |
| EVGA GeForce GTX 980 Ti Hydro Copper | 06G-P4-4999 | 1140/1228/7010 | Single | Water Block | 8+6-Pin | 6+2 | 250W | Extreme Water | Yes |
| EVGA GeForce GTX 980 Ti HYBRID | 06G-P4-1996 | 1140/1228/7010 | Single | Hybrid Cooler | 8+6-Pin | 6+2 | 250W | Extreme Water | Yes |
| EVGA GeForce GTX 980 Ti Classified ACX 2.0+ | 06G-P4-4998 | 1190/1291/7010 | Double | ACX 2.0 | 8+8-Pin | 14+3 | 300W | Ultra | Yes |
| EVGA GeForce GTX 980 Ti FTW ACX 2.0+ | 06G-P4-4996 | 1190/1291/7010 | Double | ACX 2.0 | 8+8-Pin | 8+2 | 275W | Ultra | Yes |
| EVGA GeForce GTX 980 Ti Superclocked+ ACX 2.0+ | 06G-P4-4995 | 1102/1190/7010 | Single | ACX 2.0 | 8+6-Pin | 6+2 | 250W | Extreme | Yes |
| EVGA GeForce GTX 980 Ti Superclocked ACX 2.0+ | 06G-P4-4993 | 1102/1190/7010 | Single | ACX 2.0 | 8+6-Pin | 6+2 | 250W | Extreme | N/A |
| EVGA GeForce GTX 980 Ti ACX 2.0+ | 06G-P4-4991 | 1000/1076/7010 | Single | ACX 2.0 | 8+6-Pin | 6+2 | 250W | Great | N/A |
| EVGA GeForce GTX 980 Ti Superclocked | 06G-P4-4992 | 1102/1190/7010 | Single | Single Fan | 8+6-Pin | 6+2 | 250W | Better | N/A |
| EVGA GeForce GTX 980 Ti | 06G-P4-4990 | 1000/1076/7010 | Single | Single Fan | 8+6-Pin | 6+2 | 250W | Good | N/A |
Specs
Features
- 8+2 Phase PWM
- Dual BIOS Support
- NVIDIA Dynamic Super Resolution Technology
- NVIDIA MFAA Technology
- NVIDIA GameWorks Technology
- NVIDIA GameStream Technology
- NVIDIA G-SYNC Ready
- Microsoft DirectX 12 (feature level 12_1)
- NVIDIA GPU Boost 2.0
- NVIDIA Adaptive Vertical Sync
- NVIDIA Surround Technology
- NVIDIA SLI Ready
- NVIDIA CUDA Technology
- OpenCL Support
- HDMI 2.0, DisplayPort 1.2 and Dual-link DVI
- PCI Express 3.0
- EVGA ACX 2.0 Cooling
- dB Inverter
- Memory MOSFET Cooling Plate
Core
- 2816 CUDA Cores
- Base Clock: 1190 MHz
- Boost Clock: 1291 MHz
- Bus: PCI-E 3.0
- 2-way, 3-way, 4-way SLI Ready
Memory
- Memory Detail: 6144 MB GDDR5
- Momory Bit Width: 384 Bit
- Memory Clock: 7010 MHz
- Memory Speed: 0.28 ns
- Memory Bandwidth: 336.5 GB/s
